Furtun teflon PFA, rola 50m

Tuburile de teflon antistatic PFA pot inlocui cu succes tuburile de otel inox, oferind in plus o mai mare flexibilitate, reducere a greutatii, montare mai usoara si rapida, asigurand in acelasi timp o inertie chimica perfecta si performante mecanice superioare.

Teflonul antistatic PFA (negru) previne toate descarcarile electrostatice in cele mai agresive medii si garanteaza un nivel de securitate foarte ridicat.

Recomandat pentru aplicatii speciale industriale, laboratoare, industria alimentara, aplicatii medicale.

Diametrele de 10 mm si 12 mm (in role de 50 m sau 100 m) sunt disponibile la cerere.

• Conformitate : ROHS
• Presiune maxima de lucru : 36 bar
• Temperatura minima de lucru : -196 ⁰C
• Temperatura maxima de lucru : 260 ⁰C
• Vacuum : 755 mmHg
• Lungime : 50 m
• Materialul tubului : PFA (teflon) de inalta puritate sau colorat

Informatii de la producator

Selectati codul produsului:

1050T04P00 1050T04P12 1050T04P13 1050T04P14 1050T06P00 1050T06P12 1050T06P13 1050T06P14 1050T08P00 1050T08P12 1050T08P13 1050T08P14 1050T10P00 1050T10P12 1050T10P14 1050T12P00 1050T12P12 1050T12P14

Fluoropolymer (PFA) Tubing

Parker Legris PFA tubing offers 10 times greater durability than other fluoropolymer tubings under severe chemical and mechanical conditions. This tubing range is available in three material grades, offering perfect compatibility with all applications.

PART NUMBER: 1050T04P00 Color: NATURAL Length (m): 50 Tube I.D. (mm): 2 Tube O.D. (mm): 4 Tubing Material: PFA CLEAR

• PRODUCT OVERVIEW
• TECH SPECIFICATIONS
• PRODUCT SUPPORT
• CAD

Parker Legris PFA tubing offers 10 times greater durability than other fluoropolymer tubings under severe chemical and mechanical conditions. This tubing range is available in three material grades, offering perfect compatibility with all applications.

Features/Benefits:

- Great Versatility

• Exceptional chemical inertia

• A flexible alternative to stainless steel tubing

• Broad range of working temperatures, from cryogenic to extreme heat

• Non-stick properties allowing conveyance of many fluids & gases

• Outstanding resistance to ageing

• Fluoropolymer with the lowest permeability

• Non-flammable

• UV-transparent

• Tube marking on request

• Silicone-free

- Three Material Grades

• Clear PFA: to cover all applications, including those requiring maximum mechanical resistance

• Colored PFA: for circuit identification

• Black Antistatic PFA: eliminates all risk of electrostatic discharge

Markets:

• Food and Beverage

• Power Generation Equipment

• Aircraft

• Pharmaceutical

• Medical

• Oil and Gas

Applications:

• Applications Subjected to Severe Mechanical and Chemical Conditions

• Medical Fluids Conveying

• Gas and Compressed Air Conveying

• Applications Requiring Very Low and High Temperature

• Fire Hazard Zones

• Applications Subjected to Intensive Cleaning

• Suitable for Fuel Cells and Clean Rooms

• Thermal Management

Technologies:

• Fluoropolymer Tubing

• PFA Tubing

• Perfluoro alkoxy Tubing

• Anti Static Tubing

• Industrial Tubing

Maximum Operating Pressure	33 bar
Minimum Operating Temperature	-40 °C
Maximum Operating Temperature	150 °C See the Graph “Working Pressure/Working Temperature”
Vacuum Pressure Rating	755 mm-Hg
Weight	1.056 kg/package
Application	Aircraft
Application	Chemicals
Application	Clean Rooms
Application	Food Processing
Application	Medical
Application	Oil & Gas
Application	Pharmaceutical
Media	Compressed Air
Media	Food & Beverage
Media	Industrial Gases
Media	Medical Fluids
Specifications Met	FDA 21 CFR 177.1550 (clear)
Specifications Met	PED 97/23/EC (Industrial)
Specifications Met	REACH 1907/2006 (Industrial)
Specifications Met	RoHS 2002/95/EC, 2011/65/EC (Industrial)
Specifications Met	UL 94 V-0 (Fire Resistance, Industrial)
Specifications Met	USP Class VI (A). Medical: External Communication Devices

Declaration Regarding Regulation (EC) No. 1907/2006 of the European Parliament and the Council Dated 18 December 2006 Concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Published on 30 December 2006 in the Official Journal of the European Union 396/1.	view
Tubing Part Number Identification\r	view
Interactive Medical Device Manufacturing Product Selector Infographic	view
Certificate of conformity - 1935-2004 & FDA_tube PFA, European and US foodstuff contact regulations.\r	view
Fluoropolymer Tubing PFA Datasheet	view
Certificate of conformity - Mineral Conflict Statement_connectic.	view
Fluid Handling Solutions - push-in fittings, quick couplings and piping networks - for Tempering & Cooling.	view
LPCE Webinar Thermal Management	view
Discover with this video the Parker LPCE quick connection solutions for Thermal Management in electronic applications.\rThis video shows how rigid piping, quick coupling and push-in fittings meet the requirements of liquid cooling circuits in electronic applications, such as Data Centres, Supercomputers, Electronic devices and Semiconductor production\r	view
Certificat de conformité - RoHS LPCE : déclaration de conformité selon la directive VLE 2011/65/CE sur les substances dangereuses.	view
Discover with this video the Parker LPCE quick connection solutions for liquid cooling circuit required in electrical devices. This video shows how rigid piping, quick coupling and push-in fittings can meet the requirements of thermal management in the power generation applications, such as Lithium-ion (Li-ion) batteries, Energy Storage Systems (ESS), Inverters, Rectifiers, Converters, Power Conversion Systems (PCS), Medium Voltage Drives and Variable Frequency Drives.	view

• Catalog tuburi teflon : Deschide
• Tabel compatibilitate fluide : Deschide
