Furtun teflon antistatic PFA, rola 10m
Tub de teflon antistatic PFA - alternativa de succes pentru tuburile de inox.
Presiune maxima de lucru: 36 bar
Temperatura: -196⁰C ... +260⁰C
Vacuum: 755 mmHg
Tuburile de teflon antistatic PFA pot inlocui cu succes tuburile de otel inox, oferind in plus o mai mare flexibilitate, reducere a greutatii, montare mai usoara si rapida, asigurand in acelasi timp o inertie chimica perfecta si performante mecanice superioare.
Teflonul antistatic PFA (negru) previne toate descarcarile electrostatice in cele mai agresive medii si garanteaza un nivel de securitate foarte ridicat.
Recomandat pentru aplicatii speciale industriale, laboratoare, industria alimentara, aplicatii medicale.
Diametrele de 10 mm si 12 mm (in role de 50 m sau 100 m) sunt disponibile la cerere.
- Conformitate : ROHS
- Presiune maxima de lucru : 36 bar
- Temperatura minima de lucru : -196 ⁰C
- Temperatura maxima de lucru : 260 ⁰C
- Vacuum : 755 mmHg
- Lungime : 10 m
- Materialul tubului : PFA (teflon) antistatic
Informatii de la producator
Fluoropolymer (PFA) Tubing
Parker Legris PFA tubing offers 10 times greater durability than other fluoropolymer tubings under severe chemical and mechanical conditions. This tubing range is available in three material grades, offering perfect compatibility with all applications.
Parker Legris PFA tubing offers 10 times greater durability than other fluoropolymer tubings under severe chemical and mechanical conditions. This tubing range is available in three material grades, offering perfect compatibility with all applications.
Features/Benefits:
- Great Versatility
• Exceptional chemical inertia
• A flexible alternative to stainless steel tubing
• Broad range of working temperatures, from cryogenic to extreme heat
• Non-stick properties allowing conveyance of many fluids & gases
• Outstanding resistance to ageing
• Fluoropolymer with the lowest permeability
• Non-flammable
• UV-transparent
• Tube marking on request
• Silicone-free
- Three Material Grades
• Clear PFA: to cover all applications, including those requiring maximum mechanical resistance
• Colored PFA: for circuit identification
• Black Antistatic PFA: eliminates all risk of electrostatic discharge
Markets:
• Food and Beverage
• Power Generation Equipment
• Aircraft
• Pharmaceutical
• Medical
• Oil and Gas
Applications:
• Applications Subjected to Severe Mechanical and Chemical Conditions
• Medical Fluids Conveying
• Gas and Compressed Air Conveying
• Applications Requiring Very Low and High Temperature
• Fire Hazard Zones
• Applications Subjected to Intensive Cleaning
• Suitable for Fuel Cells and Clean Rooms
• Thermal Management
Technologies:
• Fluoropolymer Tubing
• PFA Tubing
• Perfluoro alkoxy Tubing
• Anti Static Tubing
• Industrial Tubing
| Maximum Operating Pressure | 33 bar |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | 150 °C |
| Vacuum Pressure Rating | 755 mm-Hg |
| Weight | 0.243 kg/package |
| Application | Aircraft |
| Application | Chemicals |
| Application | Clean Rooms |
| Application | Food Processing |
| Application | Medical |
| Application | Oil & Gas |
| Application | Pharmaceutical |
| Media | Compressed Air |
| Media | Food & Beverage |
| Media | Industrial Gases |
| Media | Medical Fluids |
| Specifications Met | ATEX 94/9/EC (black tubing, industrial) |
| Specifications Met | FDA 21 CFR 177.1550 (clear) |
| Specifications Met | PED 97/23/EC (Industrial) |
| Specifications Met | REACH 1907/2006 (Industrial) |
| Specifications Met | RoHS 2002/95/EC, 2011/65/EC (Industrial) |
| Specifications Met | UL 94 V-0 (Fire Resistance, Industrial) |
| Specifications Met | USP Class VI (A). Medical: External Communication Devices |
