Filtru-regulator, seria P31 Parker Global

Tip produs: P31EB
Parker

Presiune maxima intrare: 10 bar / 17 bar
Presiune maxima iesire: 2 bar / 4 bar / 8 bar / 16 bar
Temperatura: -10⁰C ... +52⁰C / +65,5⁰C

Filtru-regulator Parker Global, ansamblu compact compus din filtru de aer + regulator de presiune.

Element filtrare: 5µ
Presiune maxima intrare (pahar plastic): 10 bar
Presiune maxima intrare (pahar metal): 17 bar
Presiune maxima iesire: 2 bar / 4 bar / 8 bar / 16 bar
Temperatura (pahar plastic): -10⁰C ... +52⁰C
Temperatura (pahar metal): -10⁰C ... +65,5⁰C

Informatii de la producator

Global FRL Filter Regulators

Global FRL filter/regulators provide accurate pressure regulation and high moisture removal efficiency. These filter/regulators are a one-piece unit that minimizes space by incorporating a filter and regulator into one.

Global FRL filter/regulators come in mini, compact and standard sizes. These filter/regulators provide accurate pressure regulation and high moisture removal efficiency in a one piece combined filter/regulator, minimizing space. With a balanced poppet design and a 5 micron filter element this filter/regulator delivers quick response, accurate pressure regulation and a high rate of particulate removal. For low flow and space restricted applications this product can provide a solution that does not sacrifice performance. The Global filter/regulators can also be mounted using a modular connector to other Global FRL air preparation product. The various options available such as auto drain, manual drain, gauge, assortment of bowl/drain options, and pressure range make this series easy to design to your application.


Markets

  •   Machine Tools

  •   Misc. Industrial

  •   Misc. Manufacturing

  •   Air and Gas

  •   Appliances

  •   Factory Automation

  •   Entertainment Automation

  •   Molding

  •   Packaging Machinery

  •   Printing and Marking Equipment

  •   Vehicle Assembly Facilities

  •   Wearing Apparel

  •   Food and Beverage

  •   Misc. Processing


Features/Benefits

  •  Integral ports (NPT, BSPP, BSPT)

  •  High efficiency 5 micron element as standard

  •  Excellent water removal efficiency

  •  Robust but lightweight aluminum construction

  •  Positive bayonet latch to ensure correct & safe fitting

  •  Secondary pressure ranges 0-2 bar (0-30 psig), 0-4 bar, (0-60 psig), 0-8 bar (0-125 psig), 0-16 bar (0-232 psig)

  •  Secondary aspiration plus balanced poppet provides quick response and accurate pressure regulation


Applications

  •   To be used in combination with valves and cylinders

  •   To protect tools and cylinder against corrosion

  •   To reduce friction

  •   At the transfer point from workshop to machine

  •   In combination with tools for assembly and on the shop floor

  •   For all type of machines and tools pneumatic driven

Port Size 1/4 inch
Bowl Type Poly, with Bowl Guard
Drain Option Manual
Filter Element Type 5 micron
Outlet Pressure Rating 8 bar
Pressure Gauge Type Square
Pressure Regulator Type Relieving
Global FRL product tutorial and demo view
Pneumatic Calculator, 2018 view
Air Preparation Systems - FRL, You need clean dry air! view
Library of available B10 datasheets for Pneumatic Division products view
Global Air Preparation Product Poster, 2017 view
0700P-8 Catalog Air Preparation Products, Miniature / Inline Products: P31 Series, 02 Series, 14 Series, 05 Series, P3A-R Series, R34 Series, R25 Series, R45 Series, 27 Series(Revised 05-14-20) view
Updated Parker Global and P3Y Air Preparation System, Catalog 0760P-1 (Revised 09/28/20). view
FRL Filter/Regulators, Installation and Service Manuals. (Revised 02-14-18) view
0700P-8 Catalog Air Preparation Products, Global FRL Products\r view
  • Catalog gama Parker Global FRL si P3Y : Deschide
  • Catalog filtre-regulatoare seria P31 Parker Global : Deschide
  • Catalog filtre-regulatoare seria P31 Parker Global 2024 : Deschide
Cod Racord aer Debit dm³/s Grad de filtrare Purjare Pahar Info Stoc Cerere oferta
P31EB12EGMBNTP G1/4 35 manuala plastic manometru* inclus
Adauga
P31EB12EGBBNTP G1/4 35 semi-automata plastic manometru* inclus
Adauga
P31EB12EMMBNTP G1/4 35 manuala metal manometru* inclus
Adauga
P31EB12EMBBNTP G1/4 35 semi-automata metal manometru* inclus
Adauga
