Permite controlul independent al debitului si al formei jetului de apa cu ajutorul parghiei pistolului si respectiv al duzei reglabile.
Se pot obtine jeturi puternice pentru spalare, clatire, umplere sau ceata fina.
- Conformitate : ROHS
- Presiune maxima de lucru : 20 bar
- Temperatura minima de lucru : -20 ⁰C
- Temperatura maxima de lucru : 100 ⁰C
- Corp : zamac
- Sub-base : alama nichelata
- Duza : alama nichelata
- Parghie actionare : zamac
- Garnituri : NBR (cauciuc)
- Manson : polimer tehnic
Informatii de la producator
Metal Blowguns and Water Pistols

This range of robust blowguns guarantees a longer service life under severe conditions (crushing, impact, shock and corrosion).It includes two versions to meet all requirements for blowing and spraying in industrial applications.
Features/Benefits:
- Workshop Blowgun
• Compact for easy incorporation into compressed air ring mains
• Nickel-plated forged brass for increased corrosion resistance
- Water Pistol
• Intended for the transmission of water and fluids
• Designed for precise flow control and optimisation of the power and shape of the jet
• Optimum use of industrial fluids
• Excellent ergonomics and service life
Markets:
• Factory Automation
• Miscellaneous manufacturing
• Packaging
• Vehicle Assembly Facilities
Applications:
• Suitable for Applications in Severe Conditions
• Manufacturing Workshops
• Cleaning
• Cooling
• Ejection
Technologies:
• Water pistol
• Water transmission
• Adjustable nozzle
• Corrosion resistance
• Water transmission
• Air blower gun
Technical Characteristics:
• Fluids:
Metal blowgun: compressed air, industrial fluids
Water pistol: water, oil, industrial fluids
• Materials: treated steel, nickel-plated brass, painted steel, nickel-plated steel, treated zamak, chromium-plated zamak, nickel-plated forged brass, nitrile, silicone free
• Pressure:
Metal blowgun: 0 to 10 bar
Water pistol: 10 to 20 bar
• Temperature:
Metal blowgun:
air: -15°C to +50°C
dry air: -20°C to 80°C
Water pistol: -20°C to +100°C
Regulations:
Compliance for all blowguns:
• DI: 97/23/EC (PED)
• DI: 2002/95/EC (RoHS), 2011/65/EC
• DI: 1907/2006 (REACH)
Product Types:
• Lever-Operated Blowgun, Female BSPP Thread
• Button-Operated Blowgun, Female BSPP Thread
• Water Pistol
• Adjustable Nozzle
Body Material | ZAMAK, Nickel Plated |
Brand | Legris |
Brand | Parker |
Connection Size | n/a |
Connection Type | n/a |
Division | Low Pressure Connectors Europe Division |
For Fluid Type | Metal Blowgun: Compressed air, industrial fluids -- Water Pistol: Water, oil, industrial fluids |
Industry | Industrial |
Maximum Operating Temperature | 212 °F |
Minimum Operating Temperature | 5 °F |
Product Type | Water pistol |
Shape | Water Pistols |
Technology | Fluid & Gas Handling |
Technology | Pneumatics |
O-Ring Material | NBR |
Maximum Operating Pressure | 20 bar |
Minimum Operating Temperature | -20 °C |
Maximum Operating Temperature | 100 °C |
Quantity per Box | 1 |
Weight | 0.468 kg |
Application | Manufacturing Workshops, Assembly machines, Robotics, Ejection, Cooling, Packaging, Automotive Process |
Specifications Met | Compliance for all blowguns: DI: 97/23/EC (PED), DI: 2002/95/EC (RoHS), 2011/65/EC, DI: 1907/2006 (REACH) |
Declaration Regarding Regulation (EC) No. 1907/2006 of the European Parliament and the Council Dated 18 December 2006 Concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Published on 30 December 2006 in the Official Journal of the European Union 396/1. | view |
Metal Blowguns and Water Pistols Datasheet | view |
Quick Coupling Products - Quick Couplings, Swivels, Valves, Diagnostic Sensors and Equipment | view |
Certificate of conformity - Mineral Conflict Statement_connectic. | view |
Inventor of push-in fittings and market leader in quick couplings, Parker Legris Rectus has a reputed experience in fluid transfer for production automation, transportation, food processing, thermal management and medical applications. | view |
Certificat de conformité - RoHS LPCE : déclaration de conformité selon la directive VLE 2011/65/CE sur les substances dangereuses. | view |
2299 12 01 | Part Solutions |
Cod | H mm | L mm | DN mm | Stoc | Cerere oferta |
---|---|---|---|---|---|
2299 12 01 | 140 | 126 | 12 |
|
