Cupla rapida mama, cu stut, seria Midi, DN 12, cu supapa de inchidere
Tip produs: 2511
Presiune maxima de lucru: 20 bar
Temperatura: -20⁰C ... +100⁰C
Cupla rapida mama, cu stut pentru furtun si supapa de inchidere, seria Midi, DN 12
Impreuna cu o cupla pereche tata din aceeasi serie si DN, formeaza un cuplaj rapid pentru instalatii de apa sau aer comprimat.
- Conformitate : ROHS
- Presiune maxima de lucru : 20 bar
- Temperatura minima de lucru : -20 ⁰C
- Temperatura maxima de lucru : 100 ⁰C
- Corp : alama nichelata
- Garnituri : NBR (cauciuc)
- Arc : otel inox
Informatii de la producator
Metal Quick-Acting Couplers
Parker Legris offers a range of metal couplers compatible with a large selection of fluids.<br/>Simple to install, with or without shut-off valves, these couplers offer a high flow rate capability.
This product is no longer available from Parker.
| Handle Type | na |
| Maximum Operating Pressure | 20 barg |
| Minimum Operating Temperature | -20 °C |
| Maximum Operating Temperature | 100 °C |
| Quantity per Box | 5 |
| Weight | 0.145 kg |
| Application | Workshops, Flushing, Spraying, Packaging, Factory Automation, Filling Systems, Cleaning |
| Media | Compressed air, water |
| This 28-page catalogue promotes the comprehensive range of metal Quick Acting Couplers. | view |
| Declaration Regarding Regulation (EC) No. 1907/2006 of the European Parliament and the Council Dated 18 December 2006 Concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Published on 30 December 2006 in the Official Journal of the European Union 396/1. | view |
| Tubing Part Number Identification\r | view |
| Certificate of conformity - Mineral Conflict Statement_connectic. | view |
| Metal Quick-Acting Couplers Datasheet | view |
| Metal Quick-Acting Couplers 2 Datasheet | view |
| Inventor of push-in fittings and market leader in quick couplings, Parker Legris Rectus has a reputed experience in fluid transfer for production automation, transportation, food processing, thermal management and medical applications. | view |
| Certificat de conformité - RoHS LPCE : déclaration de conformité selon la directive VLE 2011/65/CE sur les substances dangereuses. | view |
- Catalog cuple rapide seriila Midi si Maxi : Deschide
