Cilindru pneumatic ISO 15552, Ø80, seria P1F
Tip produs: P1F Ø80
- dubla actionare, magnet pentru senzori
- amortizare reglabila la capat de cursa
- diametru piston: Ø80 mm
- standard: ISO 15552
Cilindri pneumatici P1F, dubla actionare cu amortizare reglabila la capat de cursa si magnet pentru senzori.
- dubla actionare
- amortizare reglabila la capat de cursa
- magnet pentru senzori
- diametru piston: Ø80 mm
- standard: ISO 15552,
variante constructive disponibile:
- gama standard de temperatura: -20⁰C ... +80⁰C
- varianta ATEX: -20⁰C ... +60⁰C
- pentru temperaturi scazute: -40⁰C ... +80⁰
- pentru temperaturi inalte: -10⁰C ... +150⁰C
- pentru medii agresive (etansare tija FKM): -10⁰C ... +80⁰C
- pentru medii agresive (metal scraper): -30⁰C ... +80⁰C
| Cod | Diametru piston mm | Cursa mm | Racord aer (EE) | Diametru tija (ØD) mm | Stoc | Cerere oferta |
|---|---|---|---|---|---|---|
| P1F-S080MS-0025-0000 | 80 | 25 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0030-0000 | 80 | 30 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0040-0000 | 80 | 40 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0050-0000 | 80 | 50 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0060-0000 | 80 | 60 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0070-0000 | 80 | 70 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0080-0000 | 80 | 80 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0100-0000 | 80 | 100 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0125-0000 | 80 | 125 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0130-000 | 80 | 130 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0135-000 | 80 | 135 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0140-0000 | 80 | 140 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0150-0000 | 80 | 150 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0160-0000 | 80 | 160 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0200-0000 | 80 | 200 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0220-0000 | 80 | 220 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0250-0000 | 80 | 250 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0280-0000 | 80 | 280 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0320-0000 | 80 | 320 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0400-0000 | 80 | 400 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0500-0000 | 80 | 500 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0600-0000 | 80 | 600 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0650-0000 | 80 | 650 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0680-0000 | 80 | 680 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0700-0000 | 80 | 700 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0800-0000 | 80 | 800 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-0850-0000 | 80 | 850 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-1000-0000 | 80 | 1000 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-1400-0000 | 80 | 1400 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-1800-0000 | 80 | 1800 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-2000-0000 | 80 | 2000 | G3/8 | 25 |
|
Adauga |
| P1F-S080MS-2200-0000 | 80 | 2200 | G3/8 | 25 |
|
Adauga |
