Cilindru pneumatic ISO 15552, Ø32, seria P1F
Tip produs: P1F Ø32
- dubla actionare, magnet pentru senzori
- amortizare reglabila la capat de cursa
- diametru piston: Ø32 mm
- standard: ISO 15552
Cilindri pneumatici P1F, dubla actionare cu amortizare reglabila la capat de cursa si magnet pentru senzori.
- dubla actionare
- amortizare reglabila la capat de cursa
- magnet pentru senzori
- diametru piston: Ø32 mm
- standard: ISO 15552,
variante constructive disponibile:
- gama standard de temperatura: -20⁰C ... +80⁰C
- varianta ATEX: -20⁰C ... +60⁰C
- pentru temperaturi scazute: -40⁰C ... +80⁰
- pentru temperaturi inalte: -10⁰C ... +150⁰C
- pentru medii agresive (etansare tija FKM): -10⁰C ... +80⁰C
- pentru medii agresive (metal scraper): -30⁰C ... +80⁰C
| Cod | Diametru piston mm | Cursa mm | Racord aer (EE) | Diametru tija (ØD) mm | Stoc | Cerere oferta |
|---|---|---|---|---|---|---|
| P1F-S032MS-0010-0000 | 32 | 10 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0015-0000 | 32 | 15 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0025-0000 | 32 | 25 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0030-0000 | 32 | 30 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0040-0000 | 32 | 40 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0050-0000 | 32 | 50 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0060-0000 | 32 | 60 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0065-0000 | 32 | 65 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0080-0000 | 32 | 80 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0100-0000 | 32 | 100 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0110-0000 | 32 | 110 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0120-0000 | 32 | 120 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0125-0000 | 32 | 125 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0160-0000 | 32 | 160 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0200-0000 | 32 | 200 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0250-0000 | 32 | 250 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0320-0000 | 32 | 320 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0400-0000 | 32 | 400 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0500-0000 | 32 | 500 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0600-0000 | 32 | 600 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0610-0000 | 32 | 610 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0700-0000 | 32 | 700 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0850-000 | 32 | 850 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-0950-000 | 32 | 950 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-1100-0000 | 32 | 1100 | G1/8 | 12 |
|
Adauga |
| P1F-S032MS-1300-0000 | 32 | 1300 | G1/8 | 12 |
|
Adauga |
