Valva 5/3, seria S9, actionare electrica, centru ventilat
Tip produs: S9 581RFE
- valve 5/3, seria S9 cu porturi G1/8, G1/4, sau G1/2
- actionare electrica, centru ventilat
- distribuitor 5/3, seria S9 cu porturi G1/8, G1/4, sau G1/2
- control electric (actionare electrica)
- centru ventilat
- Presiune de lucru : 2 ... 10 bar
- Temperatura minima de lucru : -10 ⁰C
- Temperatura maxima de lucru : 60 ⁰C
| Cod | Racord aer | Debit l/min | Tip | Stoc | Cerere oferta |
|---|---|---|---|---|---|
| PA10334-0033-00 | G1/8 | 500 | S9 581RFE-1/8 |
|
Adauga |
| PA10334-0233 | G1/8 | 500 | S9 581RFE-1/8-24Vdc |
|
Adauga |
| PA10334-6133 | G1/8 | 500 | S9 581RFE-1/8-220Vac |
|
Adauga |
| PA12706-0033-00 | G1/4 | 1300 | S9 581RFE-1/4 |
|
Adauga |
| PA12706-6133 | G1/4 | 1300 | S9 581RFE-1/4-220Vac |
|
Adauga |
| PA12706-0233 | G1/4 | 1300 | S9 581RFE-1/4-24Vdc |
|
Adauga |
| PA16177-0033-00 | G1/2 | 3500 | S9 581RFE-1/2 |
|
Adauga |
| PA16177-0233 | G1/2 | 3500 | S9 581RFE-1/2-24Vdc |
|
Adauga |
| PA16177-6133 | G1/2 | 3500 | S9 581RFE-1/2-220Vac |
|
Adauga |
