Regulator compact de debit la intrare, plug-in

Regulator compact de debit la intrare, plug-in

Tip produs: 7031

Drosel compact pentru evacuare tip banjo, plug-in cu racord push-in si surub de reglaj extern.

Presiune maxima de lucru: 10 bar
Temperatura: 0⁰C ... +70⁰C

Drosel compact pentru alimentare (B) tip banjo, plug-in cu racord push-in si surub de reglaj extern.
- se monteaza prin impingere (plug-in) intr-un racord push-in sau cartridge
- reglaj progresiv ferm si precis
- piulita de blocare pentru asigurarea stabilitatii reglajului
- poate fi utilizat in toate instalatiile pneumatice datorita dimensiunilor reduse si performantelor inalte

Informatii de la producator

Selectati codul produsului:

Pneumatic Flow Control Regulators in Polymer or Nickel-Plated Brass

Parker Legris flow control regulators, available with polymer, nickel-plated brass, stainless steel, or aluminium bodies and featuring external or recessed adjustment screws, offer precise adjustment, consistent control, and compactness.

PART NUMBER: 7031 06 00 Body Material: Technical Polymer Connection 1 Size: 6 mm Connection 2 Size: 6 mm Flow Direction: Supply Product Style: Plug-In Regulators with External Adjustment

Parker Legris flow control regulators are designed for compactness and versatility, offering a range of body materials, including polymer, nickel-plated brass, stainless steel, and aluminium, to meet diverse application needs. With a higher maximum flow rate than standard regulators on the market, these regulators enhance productivity. Featuring either external or recessed adjustment screws, they enable precise adjustments and ensure reliable performance across various settings.

Features/Benefits:

- Improved Productivity

• Higher maximum flow than standard regulators

• Full flow with minimum pressure drop (model 7060)

• Optimal control of the cylinder rod speed

• 100% leak-tested in production

• Date coding to guarantee quality and traceability

• Reduce compressed air and energy consumption

- Accuracy & Performance

• Precise adjustment for accurate flow regulation from initial to maximum opening

• Constant cylinder rod displacement speed

• Long-term stability of flow

• Reduced weight (polymer version)

• Mechanical strength and corrosion resistance with nickel-plated brass version

- Ergonomics & Large Range

• External adjustment screw: easy to adjust without tooling and lockable

• Recessed adjustment screw: more compact and protects the adjustment mechanism

• Uni-directional: exhaust or inlet

• Bi-directional: adjustment of air flow in both directions

• 360° positioning

• NPT version on request

Markets:

• Factory Automation

• Vehicle Assembly Facilities

• Food and Beverage

• Semiconductor

• Packaging Machinery

Applications:

• Pneumatic Cylinder Control

• Low Pressure Compressed Air Flow Regulation and metric thread

Product Style	Plug-In Regulators with External Adjustment
Brand	Parker
Brand	Legris
Division	Low Pressure Connectors Europe Division
Industry	Industrial Manufacturing Equipment
Industry	Industrial Processing
Application	Robotics
Application	Textile
Application	Automotive Process
Application	Packaging
Technology	Pneumatics
Product Type	Function Fittings and Flow Control
Maximum Operating Pressure	10 bar
Minimum Operating Pressure	1 bar
Shape	Elbow 90°
Configuration	Tube to Tube Stem
Connection 2 Type	Tube Stem
Hex Size	10 mm
Maximum Operating Temperature	70 °C
Minimum Operating Temperature	0 °C
Flow Direction	Supply
Body Material	Technical Polymer
Seal Material	NBR
Weight	0.014 kg
Height	41 mm
Quantity per Box	10
Nut Material	Nickel-Plated Brass
For Fluid Type	Compressed air, Other fluids: contact us
Connection 1 Type	Tube
Connection 1 Size	6 mm (O.D.)
Connection 2 Size	6 mm (O.D.)
Maximum Operating Temperature	158 °F
Maximum Operating Pressure	145 psi
Minimum Operating Pressure	14.5 psi
Minimum Operating Temperature	32 °F
