Ungator aer comprimat, seria P31 Parker Global

Tip produs: P31LB
Parker

Presiune maxima: 10 bar / 17 bar
Temperatura: -10⁰C ... +52⁰C / +65,5⁰C

Lubrificator pentru aer comprimat, Parker Global

Presiune maxima (pahar plastic): 10 bar
Presiune maxima (pahar metal): 17 bar
Temperatura (pahar plastic): -10⁰C ... +52⁰C
Temperatura (pahar metal): -10⁰C ... +65,5⁰C

Informatii de la producator

Global FRL Lubricators

Global FRL lubricators inject a mist of oil into the flowing air stream to automatically provide the correct amount of internal lubrication for air tools and other pneumatic devices.

The Global FRL Lubricators are available in (3) sizes: Miniature (P31L), Compact (P32L) and Standard (P33L).  These lubricators can be precisely adjusted to a very low oil flow rate because only a portion of the oil drops seen in the sight dome travels downstream. Proportional oil is delivered over a wide range of air flows and a precision needle valve assures repeatable oil delivery. A slight adjustment can provide a desired mist rate. With the various options available, the Global FRL Lubricators are easily configurable with other Global FRL products.


These units are ideal for low and high flow applications that demand uniform lubrication in a robust package. ISO/ASTM VG32 oil is suggested for lubrication and will allow the product to perform at peak performance. Do not use oils with additives, compounded oils containing solvents, graphite, detergents or synthetic oils.


Markets

  •   Machine Tools

  •   Misc. Industrial

  •   Misc. Manufacturing

  •   Air and Gas

  •   Appliances

  •   Factory Automation

  •   Entertainment Automation

  •   Molding

  •   Packaging Machinery

  •   Printing and Marking Equipment

  •   Vehicle Assembly Facilities

  •   Wearing Apparel

  •   Food and Beverage

  •   Misc. Processing


Features/Benefits

  •   Integral ports (NPT, BSPP & BSPT): P31 - 1/4", P32 - 1/4", 3/8" & 1/2", P33 - 3/4", 1/2"

  •   Robust but lightweight aluminium construction

  •   Proportional oil delivery over a wide range of air flows

  •   Fingertip ratchet control for precise oil drip rate adjustment

  •   Ability to fill from top while under system pressure


Applications

  •   To be used in combination with valves and cylinders

  •   To protect tools and cylinder against corrosion

  •   To reduce friction

  •   At the transfer point from workshop to machine

  •   In combination with tools for assembly and on the shop floor

  •   For all type of machines and tools pneumatic driven

Port Size 1/4 inch
Bowl Type Poly, with Bowl Guard
Drain Option None
Lubricator Option Fill Plug
Product Type Miniature
Port Type BSPP
Global FRL product tutorial and demo view
Pneumatic Calculator, 2018 view
FRL Lubricators, Installation and Service Manuals (Revised 02-14-18) view
Air Preparation Systems - FRL, You need clean dry air! view
Global Air Preparation Product Poster, 2017 view
0700P-8 Catalog Air Preparation Products, Miniature / Inline Products: P31 Series, 02 Series, 14 Series, 05 Series, P3A-R Series, R34 Series, R25 Series, R45 Series, 27 Series(Revised 05-14-20) view
Updated Parker Global and P3Y Air Preparation System, Catalog 0760P-1 (Revised 09/28/20). view
0700P-8 Catalog Air Preparation Products, Global FRL Products\r view
  • Catalog gama Parker Global FRL si P3Y : Deschide
  • Catalog ungatoare aer comprimat, seria P31 Parker Global 2024 : Deschide
Cod Racord aer Debit dm³/s Pahar Stoc Cerere oferta
P31LB12LGNN G1/4 25 plastic
Adauga
P31LB12LMNN G1/4 25 metal
Adauga
