Cupla rapida tata, seria C9000, profil European, filet interior BSPP
Tip produs: 9086E
Profil standard European
Seria C9000 safety, Diametru nominal DN 7,4
self-venting system
Presiune maxima de lucru: 16 bar
Temperatura: -20⁰C ... +60⁰C
Conectare rapida si deconectare in siguranta.
Asigura debit optim pentru echipamentele si sculele pneumatice.
- Conformitate : ROHS
- Presiune maxima de lucru : 16 bar
- Temperatura minima de lucru : -20 ⁰C
- Temperatura maxima de lucru : 60 ⁰C
- Duza : otel nichelat
- Garnitura : polimer tehnic
Informatii de la producator
C 9000 Polymer Quick-Acting Safety Couplers
Note: This product is no longer available – please use the Parker cross reference tool https://crossref.parker.com/ for alternatives.
This product is no longer available from Parker.
| Coating | n/a |
| Thread Sealant Material | n/a |
| Maximum Operating Pressure | 16 barg |
| Minimum Operating Temperature | -20 °C |
| Maximum Operating Temperature | 60 °C |
| Quantity per Box | 1 |
| Weight | 0.016 kg |
| Application | Air-Operated Tools |
| Application | Blowing |
| Application | Cleaning |
| Application | Packaging |
| Application | Pneumatics |
| Application | Ring Main Circuits |
| Application | Workshops |
| Media | Compressed Air |
| Specifications Met | DIN EN 983 (Safety Standard for pneumatics) |
| Specifications Met | ISO 4414 (Pneumatic Fluid Power: General Rules Relating to Systems) |
| Specifications Met | PED (DI: 97/23/EC) |
| Specifications Met | REACH (DI: 1907/2006) |
| Specifications Met | RoHS (DI: 2002/95/EC & 2011/65/EC) |
| C9000 Polymer Quick-Acting Safety Couplers Datasheet | view |
| Tubing Part Number Identification\r | view |
| C9000 Polymer Quick-Acting Safety Couplers 2 Datasheet | view |
| Inventor of push-in fittings and market leader in quick couplings, Parker Legris Rectus has a reputed experience in fluid transfer for production automation, transportation, food processing, thermal management and medical applications. | view |
| Certificat de conformité - RoHS LPCE : déclaration de conformité selon la directive VLE 2011/65/CE sur les substances dangereuses. | view |
